Industrial chiller machines are advanced technological equipment that play a vital role in many industries. These machines are designed to provide the necessary cooling required by various industrial processes.
Characteristics of industrial chiller machine
Industrial chiller machines are characterized by reliability, high performance, and efficiency. Below are some of the positive characteristics of industrial chiller machines:
1. High Efficiency: Industrial chiller machines are designed to provide efficient and effective cooling solutions. They are designed with advanced technology that ensures maximum energy efficiency, and their high-quality components help in reducing energy consumption.
2. Reliable Performance: Industrial chiller machines are engineered to provide unmatched performance. They are built to withstand rugged industrial environments and are designed to operate seamlessly for extended periods without maintenance issues.
3. Versatility: Industrial chiller machines are versatile and customizable according to specific industrial needs. The machines can be designed to provide different levels of cooling capacities, enabling them to accommodate a wide range of applications.
4. Environmentally Friendly: Industrial chiller machines are environmentally friendly due to their efficiency and their ability to operate with low refrigerant levels.
5.Ease of Maintenance: Industrial chiller machines require minimal maintenance. The machines are designed with easy-to-repair components, making repairs and maintenance easy and cost-effective.
Moreover, these machines provide a safe and secure working environment for employees. By controlling temperature and other important factors, industrial chiller machines help to prevent accidents and other hazards that could endanger workers' health and safety.
Overall, the industrial chiller machine is an essential piece of equipment that deserves recognition for the valuable role it plays in various industries.
Scope of application of industrial chiller machine
Industrial chiller machines are widely used in various manufacturing processes that require a cool environment such as the food, pharmaceutical, and chemical industries. The scope of application of industrial chiller machines is vast and has proved to be significant in various industrial processes.
In the food industry, industrial chiller machines are used for cooling food products during and after manufacturing processes. The machines are used to control the temperature of products such as milk, cheese, yogurt, and others to ensure that they remain fresh for an extended period. This helps to extend the shelf life of food products and ensure that they are safe for consumption.
In the pharmaceutical industry, industrial chiller machines are used to maintain the temperature of various drugs and chemicals used in the manufacturing process. This ensures that the drugs are safe for use by patients and remain effective for an extended period, helping to reduce waste and cost.
Chemical companies also use industrial chiller machines to control the temperature in their production processes. They help to increase the efficiency of the production process by regulating the temperature of different chemical reactions. This ensures that the products are of high quality and meet the required standards.
Other industries that also use industrial chiller machines include the automotive industry, plastics industry, and electronics industry. The machines are used to cool equipment and maintain their optimal working temperatures, ensuring that they operate effectively and efficiently.
In conclusion, the scope of application of industrial chiller machines is vast and significant in various industrial processes. These machines have been proven to be crucial in ensuring the quality and safety of different products, thus contributing to the growth and success of different industries.
In summary, industrial chiller machines are essential in various industrial processes, and their characteristics make them dependable, efficient, eco-friendly, versatile, and easy to maintain.
Product parameters(R407C)
|
Technical Parameters of Water Cooled Scroll Chiller(Ⅰ) |
|||||||
|
Model |
SCW-05 |
SCW-08 |
SCW-10-Ⅱ |
SCW-15-Ⅲ |
SCW-20-Ⅱ |
SCW-25-Ⅱ |
|
|
Refrigerating capacity (Kcal/lKw/Rt/h) |
15093Kcal 17.55KW 4.99RT |
24148Kcal 28.08KW 7.98RT |
30186Kcal 35.1KW 9.98RT |
45279Kcal 52.65KW 14.97RT |
60372Kcal 70.2KW 19.96RT |
75465Kcal 87.75KW 24.95RT |
|
|
Refrigerant |
R407C |
||||||
|
compressor power(Hp) |
5 |
8 |
10 |
15 |
20 |
25 |
|
|
Circulating pump power(Hp) |
0.75 |
1 |
1/1.5 |
1.5/2 |
1.5/2 |
2/3 |
|
|
Piping of cooling water system |
pipe diameter |
1" |
1.5" |
1.5" |
2" |
2" |
2.5" |
|
Flow(m³/h) |
3.4 |
5.5 |
6.85 |
9.3 |
12.7 |
15.1 |
|
|
Chilled drainage piping |
pipe diameter |
1" |
1.5" |
1.5" |
2" |
2" |
2.5" |
|
Flow(m³/h) |
2.74 |
4.27 |
4.27 |
8.59 |
8.59 |
14.55 |
|
|
supply voltage |
AC380V50HZ3PH AC440V50HZ3PH AC220V60HZ3PH |
||||||
|
Description: 1.The cooling capacity is based on evaporating temperature: 7℃, condenser temperature: 40℃, refrigerant: R407C, cooling water temperature: 32-37℃ 2.Optional refrigerant:R134A / R404A / R22 |
|||||||
|
Technical Parameters of Water Cooled Scroll Chiller(Ⅱ) |
||||||
|
Model |
SCW-30-Ⅱ |
SCW-40 |
SCW-50 |
SCW-60 |
SCW-80 |
|
|
Refrigerating capacity (Kcal/lKw/Rt/h) |
90558Kcal 105.3KW 29.94RT |
120744Kcal 140.4KW 39.92RT |
150930Kcal 175.5KW 49.9RT |
181116Kcal 210.6KW 59.88RT |
241488Kcal 280.8KW 79.84RT |
|
|
Refrigerant |
R407C |
|||||
|
compressor power(Hp) |
30 |
40 |
50 |
60 |
80 |
|
|
Circulating pump power(Hp) |
3/4 |
40HP and above are configured according to customer requirements |
||||
|
Piping of cooling water system |
pipe diameter |
2.5" |
3" |
3" |
4" |
4" |
|
Flow(m³/h)
|
18.5 |
24.5 |
30.2 |
36.2 |
48.2 |
|
|
Chilled drainage piping |
pipe diameter |
2.5" |
3" |
3" |
4" |
4" |
|
Flow(m³/h) |
14.55 |
22.06 |
22.06 |
42.2 |
42.2 |
|
|
supply voltage |
AC380V50HZ3PH AC440V50HZ3PH AC220V60HZ3PH |
|||||
|
Description: 1.The cooling capacity is based on evaporating temperature: 7℃, condenser temperature: 40℃, refrigerant: R407C, cooling water temperature: 32-37℃ 2.Optional refrigerant:R134A / R404A / R22 |
||||||
|
Technical Parameters of Air - Cooled Scroll Chiller(Ⅰ) |
|||||||
|
Model |
SCA-05 |
SCA-08 |
SCA-10-Ⅱ |
SCA-15-Ⅲ |
SCA-20-Ⅱ |
SCA-25-Ⅱ |
|
|
Refrigerating capacity (Kca/lKw/Rt/h) |
13583.7Kca 15.8KW 4.5Rt |
21733.2Kca 25.3KW 7.2Rt |
27167.4Kca 31.59KW 9Rt |
40751.1Kca 47.4KW 13.5Rt |
54334.8Kca 63.18KW 18Rt |
67918.5Kca 79KW 22.5Rt |
|
|
Refrigerant |
R407C |
||||||
|
compressor power(HP) |
5 |
8 |
10 |
15 |
20 |
25 |
|
|
Circulating pump power(Hp) |
0.75 |
1 |
1/1.5 |
1.5/2 |
1.5/2 |
2/3 |
|
|
Cooling fan |
Diameter(mm) |
550 |
600 |
500 |
550 |
600 |
630 |
|
Air Volume(m³/h )
|
6487 |
10820 |
2*6264 |
2*8487 |
2*10820 |
2*12220 |
|
|
Chilled drainage piping |
Pipe diameter |
1" |
1.5" |
1.5" |
2" |
2" |
2.5" |
|
Flow(m³/h) |
2.74 |
4.27 |
4.27 |
8.59 |
8.59 |
14.55 |
|
|
Supply voltage |
AC380V50HZ3PH AC440V50HZ3PH AC220V60HZ3PH |
||||||
|
Description: 1.The cooling capacity is based on evaporating temperature: 7℃, condenser temperature: 50℃, refrigerant: R407C, cooling water temperature: 32-37℃ 2.Optional refrigerant:R134A / R404A / R22 |
|||||||
|
Technical Parameters of Air - Cooled Scroll Chiller(Ⅱ) |
||||||
|
Model |
SCA-30-Ⅱ |
SCA-40 |
SCA-50 |
SCA-60 |
SCA-80 |
|
|
Refrigerating capacity (Kcal/h) |
81502.2Kca 94.77KW 27Rt |
108669.6Kca 126.36KW 36Rt |
135837Kca 158KW 45Rt |
163004.4Kca 189.5KW 53.9Rt |
217339.2Kca 252.72KW 71.9Rt |
|
|
Refrigerant |
R407C |
|||||
|
Compressor power(HP) |
30 |
40 |
50 |
60 |
80 |
|
|
Circulating pump power(Hp) |
3/4 |
40HP以上根据客户要求配置 40HP and above are configured according to customer requirements |
||||
|
Cooling fan |
Diameter(mm) |
700 |
750 |
630 |
700 |
750 |
|
Air Volume(m³/h)
|
2*15000 |
2*19000 |
3*12220 |
3*15000 |
3*19000 |
|
|
Chilled drainage piping |
Pipe diameter |
2.5" |
3" |
3" |
4" |
4" |
|
Flow(m³/h) |
14.55 |
22.06 |
22.06 |
42.2 |
42.2 |
|
|
Supply voltage |
AC380V50HZ3PH AC440V50HZ3PH AC220V60HZ3PH |
|||||
|
Description: 1.The cooling capacity is based on evaporating temperature: 7℃, condenser temperature: 50℃, refrigerant: R407C, cooling water temperature: 32-37℃ 2.Optional refrigerant:R134A / R404A / R22 |
||||||
|
Technical Parameters of Water - Cooled Screw Chiller(Ⅰ) |
|||||||
|
Model |
RC2-40W |
RC2-50W |
RC2-60W |
RC2-80W |
RC2-90W |
RC2-100W |
|
|
Refrigerating capacity (Kca/lKw/Rt/h) |
119282Kca 138.7KW 39.4Rt |
154026Kca 179.1KW 50.9Rt |
172946Kca 201.1KW 57.2Rt |
229878Kca 267.3KW 76Rt |
287670Kca 334.5KW 95.1Rt |
314502Kca 365.7KW 104Rt |
|
|
Refrigerant |
R407C |
||||||
|
Compressor Power(Hp) |
40 |
50 |
60 |
80 |
90 |
100 |
|
|
Supply voltage |
AC380V50HZ3PH AC440V50HZ3PH AC220V60HZ3PH |
||||||
|
Energy regulation mode |
25%-50%-75%-100% |
||||||
|
Starting mode |
Y/▲ |
Y/▲ |
Y/▲ |
Y/▲ |
Y/▲ |
Y/▲ |
|
|
Piping of cooling water system |
Pipe diameter |
3" |
3" |
3" |
3" |
4" |
4" |
|
Chilled drainage piping |
Pipe diameter |
3" |
3" |
3" |
3" |
4" |
4" |
|
Description: 1.The cooling capacity is based on evaporating temperature: 7℃, condenser temperature: 40℃, refrigerant: R407C, cooling water temperature: 32-37℃ 2.Optional refrigerant:R134A / R404A / R22 |
|||||||
|
Technical Parameters of Water - Cooled Screw Chiller(Ⅱ) |
|||||||
|
Model |
RC2-110W |
RC2-120W |
RC2-140W |
RC2-150W |
RC2-160W |
RC2-180W |
|
|
Refrigerating capacity (Kcal/h) |
343742Kca 399.7KW 113.6Rt |
371004Kca 431.4KW 122.7Rt |
439030Kca 510.5KW 145.2Rt |
463540Kca 539KW 153.3Rt |
512818Kca 596.3KW 169.5Rt |
571470Kca 664.5KW 188.9Rt |
|
|
Refrigerant |
R407C |
||||||
|
Compressor Power(Hp) |
110 |
120 |
140 |
150 |
160 |
180 |
|
|
Supply voltage |
AC380V50HZ3PH AC440V50HZ3PH AC220V60HZ3PH |
||||||
|
Energy regulation mode |
25%-50%-75%-100% |
||||||
|
Starting mode |
Y/▲ |
Y/▲ |
Y/▲ |
Y/▲ |
Y/▲ |
Y/▲ |
|
|
Piping of cooling water system |
Pipe diameter |
4" |
4" |
5" |
5" |
5" |
5" |
|
Chilled drainage piping |
Pipe diameter |
4" |
4" |
5" |
5" |
5" |
5" |
|
Description: 1.The cooling capacity is based on evaporating temperature: 7℃, condenser temperature: 40℃, refrigerant: RR407C, cooling water temperature: 32-37℃ 2.Optional refrigerant:R134A / R404A / R2 |
|||||||
|
Technical Parameters of Water - Cooled Screw Chiller(Ⅲ) |
|||||||
|
Model |
RC2-200W |
RC2-220W |
RC2-240W |
RC2-280W |
RC2-300W |
RC2-320W |
|
|
Refrigerating capacity (Kca/lKw/Rt/h) |
664952Kca 773.2KW 219.8Rt |
730312Kca 849.2KW 241.5Rt |
742008Kca 862.8KW 245.3Rt |
878060Kca 1021KW 290.3Rt |
927080Kca 1078KW 306.5Rt |
1025636Kca 1192.6KW 339.1Rt |
|
|
Refrigerant |
R407C |
||||||
|
Compressor Power(Hp) |
200 |
220 |
240 |
280 |
300 |
320 |
|
|
Supply voltage |
AC380V50HZ3PH/ AC440V50HZ3PH/ AC220V60HZ3PH |
||||||
|
Energy regulation mode |
25%-50%-75%-100% |
||||||
|
Starting mode |
Y/▲ |
Y/▲ |
Y/▲ |
Y/▲ |
Y/▲ |
Y/▲ |
|
|
Piping of cooling water system |
Pipe diameter |
5" |
5" |
5" |
6" |
6" |
6" |
|
Chilled drainage piping |
Pipe diameter |
5" |
5" |
5" |
6" |
6" |
6" |
|
Description: 1.The cooling capacity is based on evaporating temperature: 7℃, condenser temperature: 40℃, refrigerant: R407C, cooling water temperature: 32-37℃ 2.Optional refrigerant:R134A / R404A / R22 |
|||||||
|
Technical Parameters of Water - Cooled Screw Chiller(Ⅳ) |
||||||
|
Model |
RC2-340W |
RC2-360W |
RC2-400W |
RC2-460W |
RC2-560W |
|
|
Refrigerating capacity (Kca/lKw/Rt/h) |
1092888Kca 1270.8KW 361.3Rt |
1142940Kca 1329KW 377.9Rt |
1329904Kca 1546.4KW 439.7Rt |
1460624Kca 1698.4KW 482.9Rt |
1756120Kca 2042KW 580.6Rt |
|
|
Refrigerant |
R407C |
|||||
|
Compressor Power(Hp) |
340 |
360 |
400 |
460 |
560 |
|
|
Supply voltage |
AC380V50HZ3PH/ AC440V50HZ3PH/ AC220V60HZ3PH |
|||||
|
Energy regulation mode |
25%-50%-75%-100% |
|||||
|
Starting mode |
Y/▲ |
Y/▲ |
Y/▲ |
Y/▲ |
Y/▲ |
|
|
Piping of cooling water system |
Pipe diameter |
6" |
8" |
8" |
8" |
8" |
|
Chilled drainage piping |
Pipe diameter |
6" |
8" |
8" |
8" |
8" |
|
Description: 1.The cooling capacity is based on evaporating temperature: 7℃, condenser temperature: 40℃, refrigerant: R407C, cooling water temperature: 32-37℃ 2.Optional refrigerant:R134A / R404A / R22 |
||||||
|
Technical Parameters of Air-Cooled Screw Chiller |
||||||||
|
Model |
RC2-40A |
RC2-50A |
RC2-60A |
RC2-80A |
RC2-90A |
RC2-100A |
RC2-120A |
|
|
Refrigerating capacity (Kca/lKw/Rt/h) |
102856Kca 119.6KW 34Rt |
132870Kca 154.5KW 43.9Rt |
149124Kca 173.4KW 49.3Rt |
198230Kca 230.5KW 65.5Rt |
248110Kca 288.5KW 82Rt |
271330Kca 315.5KW 89.7Rt |
320006Kca 372.1KW 105.8Rt |
|
|
Refrigerant |
R407C |
|||||||
|
Compressor Power(Hp) |
40 |
50 |
60 |
80 |
90 |
100 |
120 |
|
|
Supply voltage |
AC380V50HZ3PH/ AC440V50HZ3PH/ AC220V60HZ3PH |
|||||||
|
Energy regulation mode |
25%-50%-75%-100% |
|||||||
|
Starting mode |
Y/▲ |
Y/▲ |
Y/▲ |
Y/▲ |
Y/▲ |
Y/▲ |
Y/▲ |
|
|
Piping of cooling water system |
Pipe diameter |
3" |
3" |
3" |
3" |
4" |
4" |
4" |
|
Description: 1.The cooling capacity is based on evaporating temperature: 7℃, condenser temperature: 50℃, refrigerant: R407C, cooling water temperature: 32-37℃ 2.Optional refrigerant:R134A / R404A / R22 |
||||||||
|
Technical Parameters of Air-Cooled Screw Chiller |
||||||||
|
Model |
RC2-40A |
RC2-50A |
RC2-60A |
RC2-80A |
RC2-90A |
RC2-100A |
RC2-120A |
|
|
Refrigerating capacity (Kca/lKw/Rt/h) |
102856Kca 119.6KW 34Rt |
132870Kca 154.5KW 43.9Rt |
149124Kca 173.4KW 49.3Rt |
198230Kca 230.5KW 65.5Rt |
248110Kca 288.5KW 82Rt |
271330Kca 315.5KW 89.7Rt |
320006Kca 372.1KW 105.8Rt |
|
|
Refrigerant |
R407C |
|||||||
|
Compressor Power(Hp) |
40 |
50 |
60 |
80 |
90 |
100 |
120 |
|
|
Supply voltage |
AC380V50HZ3PH/ AC440V50HZ3PH/ AC220V60HZ3PH |
|||||||
|
Energy regulation mode |
25%-50%-75%-100% |
|||||||
|
Starting mode |
Y/▲ |
Y/▲ |
Y/▲ |
Y/▲ |
Y/▲ |
Y/▲ |
Y/▲ |
|
|
Piping of cooling water system |
Pipe diameter |
3" |
3" |
3" |
3" |
4" |
4" |
4" |
|
Description: 1.The cooling capacity is based on evaporating temperature: 7℃, condenser temperature: 50℃, refrigerant: R407C, cooling water temperature: 32-37℃ 2.Optional refrigerant:R134A / R404A / R22 |
||||||||
Pass the Iso9001 quality system certification and CE certification
