Industrial cooling is a critical process for various manufacturing processes, as it prevents equipment damage due to overheating and helps maintain the quality of the final products. In this context, water cooled chiller plant have become a popular choice for industrial cooling applications due to their high efficiency, reliable performance, and low maintenance requirements. In this blog post, we will discuss the benefits of water chiller and how they can contribute to the success of modern industries.
What are water cooled chiller plant?
water cooled chiller plant is cooling systems that use water as a refrigerant to dissipate heat from industrial equipment and processes. They consist of a compressor, a condenser, an evaporator, and a cooling tower. The compressor compresses the refrigerant, which then flows through the condenser and releases heat to the water flowing through the cooling tower. The cooled water then returns to the evaporator to absorb more heat from the industrial processes.
Benefits of water cooled chiller plant:
1. High Efficiency: water cooled chiller plant is highly efficient compared to air-cooled systems as water has a higher heat capacity than air, allowing it to absorb more heat for each unit of energy consumed. This results in lower operating costs and energy savings for industrial processes.
2. Reliable Performance: water cooled chiller plant operate at a constant temperature, which helps maintain the stability and consistency of the industrial processes. They are also less affected by atmospheric conditions, such as temperature and humidity levels, compared to air-cooled systems.
3. Low Maintenance Requirements: water cooled chiller plant require minimal maintenance as they have fewer moving parts and are not exposed to atmospheric dust and debris. This reduces the risk of equipment failure and downtime, which can impact productivity and profitability.
4. Scalability: water cooled chiller plant is highly scalable and can be customized to meet the specific cooling requirements of different industrial processes. They can also be integrated with other industrial systems to create a comprehensive cooling solution.
Applications of water cooled chiller plant:
water cooled chiller plant is widely used in various industrial applications, including:
1. Precision machining and tooling
2. Plastic injection molding
3. Pharmaceutical manufacturing
4. Food and beverage processing
5. Chemical production
In conclusion, water cooled chiller plant is a vital component of modern industrial processes, providing efficient and reliable cooling solutions that enhance productivity, reduce costs, and improve product quality. With their high efficiency, low maintenance requirements, and scalable design, water-cooled industrial chillers are an ideal choice for industries seeking to optimize their cooling operations and achieve sustainable growth.
Product parameters(R407C)
|
Technical Parameters of Water Cooled Scroll Chiller(Ⅰ) |
|||||||
|
Model |
SCW-05 |
SCW-08 |
SCW-10-Ⅱ |
SCW-15-Ⅲ |
SCW-20-Ⅱ |
SCW-25-Ⅱ |
|
|
Refrigerating capacity （Kcal/lKw/Rt/h） |
15093Kcal 17.55KW 4.99RT |
24148Kcal 28.08KW 7.98RT |
30186Kcal 35.1KW 9.98RT |
45279Kcal 52.65KW 14.97RT |
60372Kcal 70.2KW 19.96RT |
75465Kcal 87.75KW 24.95RT |
|
|
Refrigerant |
R407C |
||||||
|
compressor power（Hp） |
5 |
8 |
10 |
15 |
20 |
25 |
|
|
Circulating pump power（Hp） |
0.75 |
1 |
1/1.5 |
1.5/2 |
1.5/2 |
2/3 |
|
|
Piping of cooling water system |
pipe diameter |
1" |
1.5" |
1.5" |
2" |
2" |
2.5" |
|
Flow（m³/h） |
3.4 |
5.5 |
6.85 |
9.3 |
12.7 |
15.1 |
|
|
Chilled drainage piping |
pipe diameter |
1" |
1.5" |
1.5" |
2" |
2" |
2.5" |
|
Flow（m³/h） |
2.74 |
4.27 |
4.27 |
8.59 |
8.59 |
14.55 |
|
|
supply voltage |
AC380V50HZ3PH AC440V50HZ3PH AC220V60HZ3PH |
||||||
|
Description: 1.The cooling capacity is based on evaporating temperature: 7℃, condenser temperature: 40℃, refrigerant: R407C, cooling water temperature: 32-37℃ 2.Optional refrigerant:R134A / R404A / R22 |
|||||||
|
Technical Parameters of Water Cooled Scroll Chiller(Ⅱ) |
||||||
|
Model |
SCW-30-Ⅱ |
SCW-40 |
SCW-50 |
SCW-60 |
SCW-80 |
|
|
Refrigerating capacity （Kcal/lKw/Rt/h） |
90558Kcal 105.3KW 29.94RT |
120744Kcal 140.4KW 39.92RT |
150930Kcal 175.5KW 49.9RT |
181116Kcal 210.6KW 59.88RT |
241488Kcal 280.8KW 79.84RT |
|
|
Refrigerant |
R407C |
|||||
|
compressor power（Hp） |
30 |
40 |
50 |
60 |
80 |
|
|
Circulating pump power（Hp） |
3/4 |
40HP and above are configured according to customer requirements |
||||
|
Piping of cooling water system |
pipe diameter |
2.5" |
3" |
3" |
4" |
4" |
|
Flow（m³/h） |
18.5 |
24.5 |
30.2 |
36.2 |
48.2 |
|
|
Chilled drainage piping |
pipe diameter |
2.5" |
3" |
3" |
4" |
4" |
|
Flow（m³/h） |
14.55 |
22.06 |
22.06 |
42.2 |
42.2 |
|
|
supply voltage |
AC380V50HZ3PH AC440V50HZ3PH AC220V60HZ3PH |
|||||
|
Description: 1.The cooling capacity is based on evaporating temperature: 7℃, condenser temperature: 40℃, refrigerant: R407C, cooling water temperature: 32-37℃ 2.Optional refrigerant:R134A / R404A / R2 |
||||||
|
Technical Parameters of Water - Cooled Screw Chiller（Ⅰ） |
|||||||
|
Model |
RC2-40W |
RC2-50W |
RC2-60W |
RC2-80W |
RC2-90W |
RC2-100W |
|
|
Refrigerating capacity （Kca/lKw/Rt/h） |
119282Kca 138.7KW 39.4Rt |
154026Kca 179.1KW 50.9Rt |
172946Kca 201.1KW 57.2Rt |
229878Kca 267.3KW 76Rt |
287670Kca 334.5KW 95.1Rt |
314502Kca 365.7KW 104Rt |
|
|
Refrigerant |
R407C |
||||||
|
Compressor Power（Hp） |
40 |
50 |
60 |
80 |
90 |
100 |
|
|
Supply voltage |
AC380V50HZ3PH AC440V50HZ3PH AC220V60HZ3PH |
||||||
|
Energy regulation mode |
25%-50%-75%-100% |
||||||
|
Starting mode |
Y/▲ |
Y/▲ |
Y/▲ |
Y/▲ |
Y/▲ |
Y/▲ |
|
|
Piping of cooling water system |
Pipe diameter |
3" |
3" |
3" |
3" |
4" |
4" |
|
Chilled drainage piping |
Pipe diameter |
3" |
3" |
3" |
3" |
4" |
4" |
|
Description: 1.The cooling capacity is based on evaporating temperature: 7℃, condenser temperature: 40℃, refrigerant: R407C, cooling water temperature: 32-37℃ 2.Optional refrigerant:R134A / R404A / R22 |
|||||||
|
Technical Parameters of Water - Cooled Screw Chiller（Ⅱ） |
|||||||
|
Model |
RC2-110W |
RC2-120W |
RC2-140W |
RC2-150W |
RC2-160W |
RC2-180W |
|
|
Refrigerating capacity （Kcal/h） |
343742Kca 399.7KW 113.6Rt |
371004Kca 431.4KW 122.7Rt |
439030Kca 510.5KW 145.2Rt |
463540Kca 539KW 153.3Rt |
512818Kca 596.3KW 169.5Rt |
571470Kca 664.5KW 188.9Rt |
|
|
Refrigerant |
R407C |
||||||
|
Compressor Power（Hp） |
110 |
120 |
140 |
150 |
160 |
180 |
|
|
Supply voltage |
AC380V50HZ3PH AC440V50HZ3PH AC220V60HZ3PH |
||||||
|
Energy regulation mode |
25%-50%-75%-100% |
||||||
|
Starting mode |
Y/▲ |
Y/▲ |
Y/▲ |
Y/▲ |
Y/▲ |
Y/▲ |
|
|
Piping of cooling water system |
Pipe diameter |
4" |
4" |
5" |
5" |
5" |
5" |
|
Chilled drainage piping |
Pipe diameter |
4" |
4" |
5" |
5" |
5" |
5" |
|
Description: 1.The cooling capacity is based on evaporating temperature: 7℃, condenser temperature: 40℃, refrigerant: RR407C, cooling water temperature: 32-37℃ 2.Optional refrigerant:R134A / R404A / R22 |
|||||||
|
Technical Parameters of Water - Cooled Screw Chiller（Ⅲ） |
|||||||
|
Model |
RC2-200W |
RC2-220W |
RC2-240W |
RC2-280W |
RC2-300W |
RC2-320W |
|
|
Refrigerating capacity （Kca/lKw/Rt/h） |
664952Kca 773.2KW 219.8Rt |
730312Kca 849.2KW 241.5Rt |
742008Kca 862.8KW 245.3Rt |
878060Kca 1021KW 290.3Rt |
927080Kca 1078KW 306.5Rt |
1025636Kca 1192.6KW 339.1Rt |
|
|
Refrigerant |
R407C |
||||||
|
Compressor Power（Hp） |
200 |
220 |
240 |
280 |
300 |
320 |
|
|
Supply voltage |
AC380V50HZ3PH/ AC440V50HZ3PH/ AC220V60HZ3PH |
||||||
|
Energy regulation mode |
25%-50%-75%-100% |
||||||
|
Starting mode |
Y/▲ |
Y/▲ |
Y/▲ |
Y/▲ |
Y/▲ |
Y/▲ |
|
|
Piping of cooling water system |
Pipe diameter |
5" |
5" |
5" |
6" |
6" |
6" |
|
Chilled drainage piping |
Pipe diameter |
5" |
5" |
5" |
6" |
6" |
6" |
|
Description: 1.The cooling capacity is based on evaporating temperature: 7℃, condenser temperature: 40℃, refrigerant: R407C, cooling water temperature: 32-37℃ 2.Optional refrigerant:R134A / R404A / R22 |
|||||||
|
Technical Parameters of Water - Cooled Screw Chiller（Ⅳ） |
||||||
|
Model |
RC2-340W |
RC2-360W |
RC2-400W |
RC2-460W |
RC2-560W |
|
|
Refrigerating capacity （Kca/lKw/Rt/h） |
1092888Kca 1270.8KW 361.3Rt |
1142940Kca 1329KW 377.9Rt |
1329904Kca 1546.4KW 439.7Rt |
1460624Kca 1698.4KW 482.9Rt |
1756120Kca 2042KW 580.6Rt |
|
|
Refrigerant |
R407C |
|||||
|
Compressor Power（Hp） |
340 |
360 |
400 |
460 |
560 |
|
|
Supply voltage |
AC380V50HZ3PH/ AC440V50HZ3PH/ AC220V60HZ3PH |
|||||
|
Energy regulation mode |
25%-50%-75%-100% |
|||||
|
Starting mode |
Y/▲ |
Y/▲ |
Y/▲ |
Y/▲ |
Y/▲ |
|
|
Piping of cooling water system |
Pipe diameter |
6" |
8" |
8" |
8" |
8" |
|
Chilled drainage piping |
Pipe diameter |
6" |
8" |
8" |
8" |
8" |
|
Description: 1.The cooling capacity is based on evaporating temperature: 7℃, condenser temperature: 40℃, refrigerant: R407C, cooling water temperature: 32-37℃ 2.Optional refrigerant:R134A / R404A / R22 |
||||||
Pass the Iso9001 quality system certification and CE certification
