Product Description
As the name implies, anti-corrosion chillers have strong corrosion resistance to cold water media or objects to be cooled on the basis of ordinary chillers. According to the nature of corrosion, they can be divided into self-corrosion and external corrosion. Generally speaking, the working place of the chiller can be separated from the corrosive process place, so we only need to do anti-corrosion treatment on the corrosive place.
According to the different levels of anti-corrosion, we can roughly be divided into the following categories, ordinary anti-corrosion, main anti-corrosion and important anti-corrosion. For example, ordinary anti-corrosion can be used if the cold medium is salt water, and general heat exchangers need to be used in the industry to become navy copper special heat exchange The navy copper is a zinc-tin-copper alloy, which has strong salt water corrosion resistance; the second is the main anti-corrosion, the general treatment method is to use a titanium heat exchanger with strong anti-corrosion ability; the last is the important anti-corrosion is generally used to be resistant to hydrogen fluoride Acid corroded graphite heat exchanger.
The anti-corrosion air-cooled chiller of Nanjing RICOM Refrigeration Equipment Co., Ltd. is divided into two types: screw and scroll.
Product Principle
Product Characteristics
1. Industrial grade microcomputer control system, accurate temperature ±1℃.
2. Complete protection measures, intelligent fault indication, high degree of automation, without special operation.
3. The main engine selects newly imported compressors from Europe, America and Japan, and the electrical part selects international brands..
4. Air - cooled - using high - efficiency fin condenser.
5. Water - cooled - high - efficiency shell - tube condenser.
6. The evaporator adopts 316 stainless steel tubes, titanium tubes and other acid-resistant materials.
7. The unit structure is beautiful and compact, simple installation.
8. A variety of refrigerants are available, including R22, R134a, R407c, etc.
9. 380V/50HZ 3PH standard designed power supply voltage, can be customized according to different requirements of customers.
Product Process
Nanjing RICOM Refrigeration Equipment Co., Ltd. adheres to the spirit of craftsmanship and creates high-quality products.
Product Parameters
Technical parameters of anti - corrosion air - cooled screw chiller | ||||||||
Model | RC2-40AD | RC2-50AD | RC2-60AD | RC2-80AD | RC2-90AD | RC2-100AD | RC2-120AD | |
Refrigerating capacity (Kcal/h) | 63898/74.3/21.1 | 84022/97.7/27.8 | 90214/104.9/29.8 | 120744/140.4/39.9 | 150414/174.9/49.7 | 167614/194.9/55.4 | 196166/228.1/64.9 | |
Refrigerant | R22/R134A/ | R22/R134A/ | R22/R134A/ | R22/R134A/ | R22/R134A/ | R22/R134A/ | R22/R134A/ | |
Compressor Power (Hp) | 40 | 50 | 60 | 80 | 90 | 100 | 120 | |
Supply voltage | AC380V50HZ3PH/ | AC380V50HZ3PH/ | AC380V50HZ3PH/ | AC380V50HZ3PH/ | AC380V50HZ3PH/ | AC380V50HZ3PH/ | AC380V50HZ3PH/ | |
Energy regulation mode | 25%-50%-75%-100% | 25%-50%-75%-100% | 25%-50%-75%-100% | 25%-50%-75%-100% | 25%-50%-75%-100% | 25%-50%-75%-100% | 25%-50%-75%-100% | |
Starting mode | Y/▲ | Y/▲ | Y/▲ | Y/▲ | Y/▲ | Y/▲ | Y/▲ | |
Piping of cooling water system | pipe diameter | 3" | 3" | 3" | 3" | 4" | 4" | 4" |
Technical parameters of anti-corrosion air-cooled scroll chiller | |||||||
Model | SCA-05D | SCA-08D | SCA-10D-Ⅱ | SCA-15D-Ⅲ | SCA-20D-Ⅱ | SCA-30-Ⅱ | |
Refrigerating capacity (Kcal/h) | 7850/9.13/2.6 | 11900/13.84/4 | 17000/19.77/5.6 | 24800/28.84/8.2 | 34000/39.54/11.2 | 49600/57.68/16.4 | |
Refrigerant | R22/R134A/ | R22/R134A/ | R22/R134A/ | R22/R134A/ | R22/R134A/ | R22/R134A/ | |
Compressor power (HP) | 5 | 8 | 10 | 15 | 20 | 30 | |
Circulating pump power (Hp) | 1 | 2 | 2 | 3 | 3 | 4 | |
Cooling fan | Diameter (mm) | 550 | 600 | 500 | 550 | 600 | 700 |
Air Volume (m³/h) | 6487 | 10820 | 2*6264 | 2*8487 | 2*10820 | 2*15000 | |
Chilled drainage piping | Pipe diameter | 1" | 1.5" | 1.5" | 2" | 2" | 2.5" |
Flow (m³/h) | 2.74 | 4.27 | 4.27 | 8.59 | 8.59 | 14.55 | |
Supply voltage | AC380V50HZ3PH | AC380V50HZ3PH | AC380V50HZ3PH | AC380V50HZ3PH | AC380V50HZ3PH | AC380V50HZ3PH | |
Customer Case
Widely used in plastic, electronics, chemical industry, chemical fiber, electroplating, food, textile, clothing, printing, blow molding, plastic absorption, medicine, preservation, construction, mechanical supporting equipment and many other industries and fields.
My company has served many industries, has a wealth of industry application experience.
FAQ
Common problems when buying products
Q: How long has your company been established?
A: Our company was founded in 2014, but most of our engineers have been in the industry for over 15 years, and our boss has been in the industry for over 20 years.
Q: Is your company a trading company?
A: Our company is a trading company, but we have our own factory.
Q: What are your terms of payment?
A: T/T pays 30% in advance and 100% before delivery.
Q: How long is your delivery time?
A: 25-30 working days for standard products and 45 working days for non-standard customization
Q: How long is the warranty?
A: If the parts are broken or damaged, within 18 months from the date of leaving the factory.
These parts are provided free of charge by our company (except for wearing parts due to quality problems).
